Shenzhen Kexint Technology Co., ltd. always upholds the principle of'complementary advantages, mutual benefit and win-win', and has established long-term cooperative relations with many well-known domestic and foreign companies. Our range of Communication Cables are made with the best ingredient. Since established, Shenzhen Kexint Technology Co., ltd. have always been in strict compliance with international standards and high ethical standards, thus offering customers highly reliable products. We have always been following the business principle of 'honesty & integrity', which ensures that the most credible services are delivered to every customer.

Model Number:OS2 LC-SC duplexType:Optical Fiber Patch Cord
Place of Origin:Guangdong, ChinaBrand Name:KEXINT
Number of Conductors:2Fiber Core:Duplex
Fiber Color:YellowFiber Type:OS2
Outer sheath:PVC, LSZHCable Diameter:3.0mm,2.0mm
Connector Type:LC-SCReturn Loss:PC≥45dB,UPC≥50dB,APC≥60dB
Insertion Loss(dB):≤0.2Certification:CE/ROHS/ISO9001
Warranty Time:1 year

Products Description
The fiber optic patch cord mainly used on patch panel or for the connection between outlets and terminal equipment.It also widely used for high bit rate data transmission,telecommunications,tesing instruments,active device terminations,LAN/WAN and FTTX.

Fiber Optic Patch cords are ultra reliable components featuring low insertion loss and return loss. They come with your choice of simplex or duplex cable configuration .Extensive range of fiber patch cables are terminated with state-of-the-art connectors and available in any combination of ST, SC, LC ,FC and MTRJ with PC, UPC or APC polish types to meet your standard or custom configurations.

technical data:
Range of Mode
Single mode or Multi mode
Cable Type
Simplex, Duplex Ziocord. or Multi-cores
Connector Style
SC, FC, ST, LC, MTRJ, E2000, MU, MPO /MTP.etc
Polish or Ferrule Interface Type
PC, UPC, APC
Cable Diameter
0.9mm, 1.2mm, 1.6mm, 1.8mm,2.0mm, 3.0mm
Outer Jacket
PVC /LSZH/OFNP
Jacket Color
SM Yellow | OM1, OM2 Orange | OM3 Aqua | OM4 Aqua or Violet | OM5 Lemon Green
Durability
500 cycles(0.2 dB max increase). 1000mate/de mate cycles
Operating Temp.
-20 ℃ to +70℃/+85℃ (armored)
Storage Temp.
-40℃ to +85℃
Connector Type
Performance Level
Standard
Elite
Connector
Mode
Endface
IL(dB)
RL(dB)
IL(dB)
RL(dB)
LC/SC/FC/ST
SM
PC
≤0.2
≥50
≤0.15
≥50
UPC
≤0.2
≥55
≤0.15
≥55
APC
≤0.2
≥60
≤0.15
≥60
MM
PC
≤0.2
≥35
≤0.15
≥35
MPO/MTP
SM
APC
≤0.7
≥60
≤0.35
≥60
MM
PC
≤0.5
≥20
≤0.35
≥20
MTRJ
SM
PC
≤0.5
≥50
/
/
MM
PC
≤0.5
≥35
/
/
