Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 /1000Mbps Ethernet rate without any adjustments. The optical interface operates at a 1000Mbps Ethernet rate. LED indicators are provided for rapidly ascertaining equipment operating status.By using switching and store-and-forward technology to enable data before the two network connections to the media.
Detail Information | |||
| Transmission Speed: | 1000Mbps | Wavelength: | 1310nm/1550nm |
|---|---|---|---|
| Connector: | SC/FC/ST | Distance: | 120KM |
| Fiber Type: | SM | Optic Wavelength: | 850nm, 1310nm, 1550nm, Tx1310/Rx1550nm, Tx1550/Rx1310 |
| Application: | FTTX | Power Output: | AC220V/0.5A,DC-48 V /0.5A, DC5V/1A,2A |
| Certification: | CE FCC RoHS ISO | ||
| High Light: | electrical sfp module,fiber optic ethernet transceiver | ||
1. Supports 10/100/1000Base-T, 1000Base-X protocol.
2. Flow control for full duplex and half duplex.
3. Supports up to 10k byte JUMBO frame.
4. Supports Fiber Port Trunking, Increasing Fiber Channel Bandwidth and Supply Fiber Channel Redundancy.
5. Supports Ports Based VLANS and TAG Based VLANS.
6. In conformity to safety code of FCC and CE MARK.
7. Connector: Multi-UTP RJ-45connector, one or two fiber connector
8. Operation mode: full duplex mode or half duplex mode
9. Power supply parameter: DC 5V 1A/2A
10. Environmental temperature: 0-50℃
11. Relative humidity: 5%-90%
12. UTP cable: Cat5 UTP cable
13. Transfer fiber: multimode(50/125, 62.5/125 or 100/140um); single mod( 8.3/125,8.7/125, 9/125 or 10/125um).
Specification:
Standard Protocol | IEEE 802.3, IEEE 802.3u, IEEE 802.3d, IEEE 802.3Q | ||||
| Band Width | RJ 45 Port : 8*10/100M | Optical Port : 1.25G | |||
| Operation Mode | Full /Half duplex mode | ||||
| Connectors | UTP: RJ-45 | Fiber connector : SC/FC/ST | |||
| LED Indicators | PWR,FX1/LINK,1000M,L/A | ||||
| UTP Cable | Cat5 UTP (within 100m) | ||||
| Fiber Cable | 9/125μm,(the max distance up to 20 -120km) | ||||
| 50/125, 62. 5/125μm(the max distance up to 2km) | |||||
| Power Supply | External Power supply | 5V, 2A | |||
| Power Consumption | ≤5W | ||||
| Environmental Parameters | Work Temperature | 0℃~50℃ | |||
| Storage Temperature | -40℃~70℃ | ||||
| Humidity | 5%~90% non-condensing | ||||
| MTBF (Hours) | >30000 | ||||
| Size and Weight | structure | Size | Gross Weight | ||
| External | 220mm*110mm*19mm | 0.74 kg | |||
| Certification | FCC Part 15 , Class A, RoHS and CE Mark | ||||
10/100/1000M Dual fiber：
| Connector type | SC | SC | SC | SC | SC |
| Fiber type | Multi-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 850nm | 1310nm | 1310nm | 1550nm | 1550nm |
Max Distance | 62.5µm: 224m |
20Km |
40Km |
60Km |
80Km |
| 50µm: 550m | |||||
| Min TX PWR | -11.0dBm | -9.0dBm | -4.0dBm | -8.0dBm | -3.0dBm |
| Max TX PWR | -6.0dBm | -5.0dBm | 0dBm | 0dBm | 0dBm |
| Sensitivity | < -18dBm | < -21dBm | < -24dBm | < -25dBm | < -25dBm |
| Link Budget | 7.0dBm | 12.0dBm | 20.0dBm | 17.0dBm | 22.0dBm |
10/100/1000M single fiber：
| Connector type | SC | SC | SC | SC |
| Fiber type | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 1310/1550nm | 1310/1550nm | 1310/1550nm | 1490/1550nm |
| Max Distance | 20Km | 40Km | 60Km | 80Km |
| Min TX PWR | -10.0dBm | -4.0/-8dBm | 0/-5.0dBm | -1dBm |
| Max TX PWR | -4.0dBm | 0dBm | 3/0dBm | 3dBm |
| Sensitivity | < -22dBm | < -25dBm | < -25dBm | < -25dBm |
| Link Budget | 12.0dBm | 20/17dBm | 25/20dBm | 24.0dBm |
Cable Connection of 10/100/1000M Series Gigabit Converter：
| Port type | Cable Type | Max.Length |
| 10/100/1000BASE-T | Cat. 5, 5E UTP, RJ-45 | 100 meters |
| 1000BASE-SX | Multi-mode Fiber of 850n (62.5/125µm) | 220 meters |
| 1000BASE-SX | Multi-mode Fiber of 850nm (50/125µm) | 550meter |
| 1000BASE-LX | Single-mode Fiber of 1310nm(9/125um) | 10-100km |
LED Indication：
Please refer to the following table for LED indication of 10/100/1000M Series Gigabit Converter
| LED | Status | Indication |
| power | ON | The Power is on |
| lnk/act | Flash | F1:FX Data,P1 and P2:TP Data |
| speed | ON | The Speed is 1000M |
Specifications of 10/100/1000M Series Gigabit Converter：
| MODEL | 1,10/100/1000M Series | 2,10/100/1000M Series | |
| STANDARD | IEEE802.3ab 1000BASE-T; | IEEE802.3ab 1000BASE-T; | |
IEEE802.3z 1000BASE-SX | IEEE802.3z 1000BASE-LX | ||
| INTERFACE | RJ-45 part x 1 (10/100/1000 Mbps) SC connector Fiber port x 1 (1000 Mbps) | ||
TP CONNECTIONS | 10/100/1000BASE-T:UTP Category 5, 5E | ||
FIBER CONNECTIONS | 1000BASE-SX:62.5/125µm or 50/125µm Multi-mode fiber, SC/FC connector | 1000BASE-LX:9 or 10/125µm Single-mode fiber ,SC/FC connector | |
LED INDICATIONS | lnk/act,speed,power | ||
| MAX.DISTANCE | 550m/220m | 10km and 20km,100km | |
| ENVIRONMENT | Operating Temp:0~+70℃ Storage Temp:-40~+85℃ Humlblty:10~90% non-condensing | ||
| POWER | 5V 2A | ||
| NET WELGHT | 500 g | ||
| EMISSION | FCC Class A, CE | ||
Typical Optical Power Budget：
| 10/100/1000M Series | |||||
| Connector | SC | SC | SC | SC | SC |
| Wavelength | 850nm | 1310nm | 1310nm | 1310nm | 1550nm |
| Typical | 550m/220m | 10Km | 20Km | 30Km | 50-100Km |
| Min TX | -11dBm | -11.0dBm | -10.0dBm | -7.0dBm | -1~-6.0dBm |
Max TX PWR | -3.0dBm | - 3.0dBm | -1.0dBm | 0.0dBm | 0.0dBm |
| Sensitivity | -18dBm | -21.0dBm | -21.0dBm | -24.0dBm | -24.0dBm |
Link Budget | 8.5dB | 12.0dB | 15.0dB | 19.0dB | 19.0dB |
Installation：
a. Turn off the power of the device/station in the network in which the media converter will be installed.
b. Ensure that there is no activity in the network.
c. Attach fiber cable from the media converter to the fiber network. The fiber connections must be Matched-Transmit socket to receive socket
d. Attach a UTP cable from the 1000Base-Tx network to the RJ-45 port on the product
e. Connect the power cord to the media converter and check if the power LED lights up. The TP Link and FX link LED will light when all the cable connections are satisfactory.
f. Turn on the power of the device/station.
