  • Products Details

People with different backgrounds purchase Wholesale optical patch cord waterproof Outdoor armoured/unarmoured fiber SC-SC 200M no matter the budget because of the effectiveness of these product. Technological innovation promotes products to achieve an invincible position in fierce competition. Compared with the traditional ones, it better meets the market demands.

Model Number:KXT- Patch cord 200MType:Drop cable Patch cord
Place of Origin:Guangdong, ChinaBrand Name:KEXINT
Use:FTTHWarranty Time:2 years
Network:NoneConnector Type::SC/APC
Fiber Type::SingmodeLength::200m
Color::BlackCertification::ISO9001:2008
Outer sheath::LSZHApplication::FTTH System
Ferrule End-face::APCWarranty::2 years

Product Description

 1 Applications:

Local Area Network (LAN)
Data communication network
Telecommunication optical transmission network
Optical access network(OAN)
Active device termination
Fiber optics data transmission
Test Equipment and CATV
Gigabit Ethernet
2. Optical Fiber Patch Cord Characteristics
2.1 Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
2.2 Ferrule End-face: PC,UPC,APC
2.3 Core Type: Single-mode (SM: 9/125um):G652D,G657A
Multimode(MM: 50/125um,62.5/125um,OM3 or OM4)
2.4 Cable Quantity: Simplex, Duplex, 6cores ,12corns, 16cores, 24cores, 36cores, 48cores...
2.5 Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
2.6 Cable Length: 1, 2, 3 meter or customized
2.7 Sheath Type: PVC, LSZH , OFNR, OFNP, Plenum ,Armored
3 . Connector Specification
Specification
SC, FC, LC
ST, MU, MT-RJ,SMA
MTP,MPO
E2000
Single-mode
Multimode
Single-mode
Multimode
Multimode
Single-mode
Single-mode
UPC
APC
PC
UPC
PC
PC
APC
UPC
APC
Insertion loss
≤0.3
≤0.3
≤0.3
≤0.3
≤0.3
≤0.7
≤0.75
≤0.3
≤0.3
Return loss
≥50
≥60
≥30
≥50
≥30
≥25
≥45
≥55
≥75
Wavelength
1310/1510
1310/1510
1310/1510
Interchangeability
≤0.2
≤0.2
≤0.2
≤0.2
Vibration
≤0.2
≤0.2
≤0.2
≤0.2
Operating temperature
-40~75
-40~75
-40~75
-40~75
Storage temperature
-45~85
-45~85
-45~85
-45~85
Cable diameter
φ3.0,φ2.0,φ0.9
φ3.0,φ2.0,φ0.9
φ3.0,φ2.0,φ0.9
Our Company
work shop
Our team
Certifications
Hot Sale
FAQ
Q1: Are you trading company or manufacturer ? A1: We are factory. Q2: How long is your delivery time? A2: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Q3: Do you provide samples ? is it free or extra ? A3: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q4: What is your terms of payment ? A4: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. Q5:Can I visit you? A5:Sure,our factory is in Shenzhen ,China.Please contact us to make an appointment. Q6:Can I negotiate the prices? A6:Yes,we may consider discounts for multiple container load of mixed goods. Q7:How much will the shipping charges be? A7:It depends on the size of your shipment and the method of shipping. We will offer the charge to you as you requested. If you have another question, pls feel free to contact us as below:
