Since the BBU+RRU mode is generally used in short-distance and indoor coverage scenarios, optical cables have to pass through corridors, indoor wiring ducts, shafts and other places. In some places, air blowing may be used. Therefore, this type is different from ordinary optical cables. In the category of special optical cables, light weight, small outer diameter, small bending radius, dry structure, flame retardant, and tensile strength are generally required for optical cables. We generally call this type of optical cable a remote optical cable (as shown below), which consists of a single-core soft optical cable, aramid armor and a low-smoke halogen-free sheath.
Remote cable due to its small diameter, light weight and many other advantages, is widely used in mobile communication. But this kind of fiber optic cable design and manufacture are different from the ordinary optical cable.
Detail Information | |||
| Sheath Color: | Black | Fiber Count: | 2 Core |
|---|---|---|---|
| Fiber Brand: | Corning/YOFC/FIBERHOME | Length Per Roll: | 2km |
| Application: | Outdoor | Type Of Optical Cable: | Power Optical Cable |
| Fiber Type: | G657A2 | Package: | Wooden Drum |
| High Light: | 2km Fiber Optic Armoured Cable,2core Fiber Optic Armoured Cable,G657A2 Power Optical cable | ||
Product Description:
1.Good mechanical property and environment property z Flame.
2.resistant performance.
3. Soft, agility, convenience for connection.
Applications:
1.Specially designed for cabling in base station;
2.Patch cord in communication equipments;
3.Indoor/Outdoor horzontal and vertical cabling.
Fiber Transmission Performance:
| Cabled Optical fiber | 62.5μm
(850nm/1300nm) | 50μm
(850nm/1300nm) | G.652
(1310nm/1550nm) | G.657
(1550nm/1625nm) |
| Max attenuation | 3.5/1.5 | 3.5/1.5 | 0.4/0.22 | 0.4/0.22 |
| Typical | 3.0/1.0 | 3.0/1.0 | 0.36/0.25 | 0.36/0.25 |
PACKAGE AND MARK:
PACKAGE
Not allowed two length units of cable in one drum, two ends should be sealed,. Two ends should be packed inside drum, reserve length of cable not less than 2 meters.
MARK
Cable Mark: Brand,Cable type,Fiber type and counts,Year of manufacture,Length marking .
TEST REPORT
Test report and certification supplied.
FAQ:
1. What is a remote optical cable?
2. Is there any oil in the optical cable?
According to the actual needs of customers, we do single core and dual cores. Normally, there is no oil, but in special environments, this kind of optical cable requires a loose tube with optical fiber oil inside.
3. Is the 0.9 sheath inside the optical cable?
The FTTH solution we made for customers in the UK and South Africa contains 0.9 sheath and fiber oil.
4.Is the optical cable lightning protection? Will it conduct electricity?
This kind of optical cable is a pure non-metal optical cable without metal inside, and can be used in aerial or antenna.
5.Does this optical cable have UV resistance?What is the service life of the optical cable?
Our optical cables are black, all made of new materials, have strong UV resistance, and can be used for more than 25 years.
6. What is the outer diameter of the optical cable?
The outer diameter of the optical cable can be produced at 5.0mm or 7.0mm.
