With strong ability of product research and development, Shenzhen Kexint Technology Co., ltd. ensures new products are launched on a regular basis. Our new product KEXINT FTTH ADSS GYXFTW Aramid Yarn FRP Fiber Optic Armoured Central Tube Power Cable is a totally new series and has different features. In recent years, we've updated technologies or higher-efficiency manufacturing of the product. Its application ranges have been expanded to the field(s) of Communication Cables. In the future,KEXINT FTTH ADSS GYXFTW Aramid Yarn FRP Fiber Optic Armoured Central Tube Power Cable will always adhere to the road of quality development, increase the investment in technology and talent introduction, always improve the core competitiveness of the enterprise, to achieve the goal of sustainable development.

Model Number:GJYFXTHType:ADSS Power cable
Place of Origin:Guangdong, ChinaBrand Name:KEXINT
Number of Conductors:2Sheath color:Black
Fiber Count:1~12 CoreFiber type:G652D OR B3
Fiber Brand:Corning/YOFC/FIBERHOMELength per roll:2km
Application:OutdoorCable Diameter:8.5mm
Operating temperature:-40℃~85℃Warranty Time:3 years
Certification:CE/ROHS/ISO9001

Products Description
Advantages of neutral bundled tube ADSS optical cable:

1. Compared with the traditional ADSS optical cable, the optical cable has a central bundle tube structure, and the structure is simple.
2. The outer diameter of the optical cable is small (the same number of cores), the optical cable is light, and the construction cost is low.
3. The production process is simple and the material used is less, so the price of the optical cable is low.   Product Description:
1.Good mechanical property and environment property z Flame. 2.resistant performance. 3. Soft, agility, convenience for connection. Applications:
1. The manufacturing process of FRP + aramid fiber makes the optical cable have a good tensile capacity, which can be used in the construction c. nvironment of the optical cable with an overhead span of 50~150 meters.
2. The entire optical cable is made of non-metallic materials, will not conduct electricity, has lightning protection, and can be used in overhead.
Cable description: Optical fibers are positioned in a loose tube made of PBT.
PE outer sheath.
The tubes are filled with a water resistant filling compound.
The tube is covered with FRP and aramid fiber as strength member.

Fiber color:
No.
1
2
3
4
5
6
Color
Blue
Orange
/
/
/
/

Tube color:
No.
1
Color
Natural

Structure parameter:
Item
Contents
Unit
Value
Fiber count
Number
/
1~12
Fiber
model
/
G657A2
Max.fibers per tube
Count
/
12
loose tube
diameter
mm
2.0
loose tube
thickness
mm
0.32
Strength member
Material 1
/
2*1.6/1.8/2.0/2.5 FRP

Material 2
/
1670*3 Aramid fiber
Outer sheath
Color
/
Black

Material
/
PE
Cable diameter
±5%
mm
8.5±0.1
Cable weight
±10%
kg/km
43.5

Mechanical & Environmental Performance
Item
Contents
Value
Max. tensile load
Short term
1300N
Max. crush resistance
Short term
2200N
Min. bending radius
Installation
15 x cable diameter

Operation
10 x cable diameter
Temperature range
Operation
-20℃ ~ +70℃

Optical fiber
Item
Unit
Specification
G. 657A2
Mode field diameter
1310nm
mm
9.2 ± 0.4
1550nm
mm
10.4 ± 0.5
Cladding diameter
mm
125.0 ± 0.7
Cladding non-circularity
%
1.0
Core concentricity error
mm
0.5
Coating diameter
mm
242 ± 7
Coating/cladding concentricity error
mm
<12
Cable cut-off wavelength
nm
< 1260
Attenuation Coefficient
1310nm
dB/km
<0.35
1550nm
dB/km
<0.21
Macro-bend loss (1 turn, 10mm radius)
1550nm
dB/km
<0.75
1625nm
dB/km
<1.5
Proof stress level
kpsi
≥100
Our advantages:

1. Good reply: Your inquiry related to our products or price will be replied within 24 hours.

2. OEM&ODM: We can help you to design or put your logo and company name into products.

3. Remote Technical support&Full Technical Document

4. Warranty: 1 year warranty( While the warranty is not responsible for those broken by violence or updated with other brands.)

5. English software, English Indicator

6. Professional, Very competitive price

7. Large Stock, Fast Delivery
