GJPFJH indoor wiring optical cable is an indoor optical cable suitable for optical cable wiring, wiring and comprehensive wiring of optical cables for various urban buildings in telecommunication projects.
The design requirements of the indoor optical cable fully consider the mechanical performance requirements of the project to resist twisting, squeezing, impact resistance and tensile resistance of the optical cable in the indoor operating environment under the principle of ensuring the transmission technical indicators of the signal in the optical fiber. And considering that the electromagnetic field radiation in the space application environment has a disturbing effect on the signal transmission in the optical fiber, and the direct intrusion effect of the hydrogen and oxygen (-OH) in the water vapor on the optical fiber, the brand-new structural design and concept in the optical cable manufacturing industry are adopted. The process method not only has the characteristics of comprehensive wiring that is convenient for construction and handling, easy to adapt to engineering specifications, and convenient for the construction personnel to operate; but also under the principle of ensuring a certain strength of mechanical properties, it greatly improves the flexibility of the optical cable and has moisture resistance, Flame retardant and anti-electromagnetic field radiation performance. It is mainly used in indoor buildings and computer rooms.
Detail Information | |||
| Outer Jacket: | PVC Or LSZH | Fiber Count: | 2/4/6/8/12/24 |
|---|---|---|---|
| Jacket: | Black Or Yellow | Fiber Type: | 9/125 And 50/125 |
| Reinforcement: | Aramid | Size: | 5.0 Cm |
| Fiber Brand: | Corning/YOFC/FIBERHOME | ||
| High Light: | armored network cable,armoured fiber cable | ||
Application:
1.Used in pigtails and patch cords;
2.Used in optical connections in optical communication equipment rooms and optical distribution frames,and optical apperatus connectors;
3.Used in indoor cabling.
Feature:
1.Excellent stripping quality;
2.Single mode and Multimodel fiber for options;
3. Flame retardant characteristics meets the requirements of relevent standards;
4. Easy to splice,good capacity of data transmission;
Fiber color coding and Tube color coding
| Color code | 1 | 2 | 3 | 4 | 5 | 6 |
| Blue | Orange | Green | Brown | Slate | White | |
| 7 | 8 | 9 | 10 | 11 | 12 | |
| Red | Black | Yellow | Violet | Rose | Aqua |
Optical cable parameters:
| Fiber Count | Outside OD(mm) | Tight Buffer OD(mm) | Weightkg/km | Tensile Strength(N) | Crush Resistance(N/100mm) | Bending Radius(mm) | |||
| 2 | 3 | 0.9 | 15 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 4 | 5 | 0.9 | 22 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 6 | 5 | 0.9 | 23 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 8 | 5.5 | 0.9 | 28 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 12 | 6 | 0.9 | 38 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 16 | 7.2 | 0.9 | 42 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 24 | 8.3 | 0.9 | 58 | 600 | 200 | 1000 | 200 | 20D | 10D |
| 48 | 10 | 0.9 | 96 | 600 | 200 | 1000 | 200 | 20D | 10D |
1. Other fiber type and material can be provided.
2. The structure dimensions can be designed according to your product performance requirements.
3. To design flame retardant, anti-rodent, termite resistant cable for you.
MARK
Cable Mark: Brand,Cable type,Fiber type and counts,Year of manufacture,Length marking .
TEST REPORT
Test report and certification supplied.
