1.6T OSFP224 DR8 Closed-top Pluggable Optical Transceiver

The 1.6T OSFP224 DR8 transceiver is designed for 1.6T Ethernet and InfiniBand communication application links over 500m of single-mode fiber (SMF), and it is compliant with OSFP MSA,CMIS 5.1, IEEE802.3dj standards. The
optical signal is transmitted over four parallel channels at a central wavelength of 1310nm.

SEND INQUIRY NOW

Data Rate	1.6Tb/s
Supply Voltage	3.3V
Power Consumption	≤ 25W
Wavelength	1310nm
Optical Connector	MPO-12/APC
Transmitter	Hyper Silicon ™ Photonics
Case Temperature	0°C to 70°C
Reach	500m

SEND INQUIRY NOW

Product Details

The module contains 8 parallel channels on the transmitter and receiver, each operating at 212.5Gbps. It is suitable for 1.6T Ethernet, Data Center, InfiniBand, Breakout 2x800G DR4 or 8x200G DR Application. The optical interface is Dual MPO-12/APC connector.

Feature

OSFP MSA 5.22 and CMIS 5.1 compliant
Dual MPO-12/APC optical connector
8x212.5Gbps (106.25GBd PAM4) electrical interface
8x212.5Gbps (106.25GBd PAM4) optical interface
Up to 500m over SMF
Power dissipation ≤ 25W
Operating case temperature: 0°C to 70°C
Compliant with IEEE802.3dj : 1.6TBASE-DR8 and
1.6TAUI-8 C2M
Built-in digital diagnostic functions
3.3V power supply voltage
RoHS compliant

Application

1.6T Ethernet
Data center networks
InfiniBand XDR
