Detail Information |
|||
| Cable Type: | Cat5e CAT6 CAT7 | MModel Number: | RJ45 |
|---|---|---|---|
| NoLine Diameter: | 5.3MM | Data Transmission Speedl: | 305M |
| Material: | Cu Or AL | Tensile Strength: | 1000N |
| Compressive Strength: | 250P | Core Number: | 4 Pairs |
| High Light: | fiber optic lan cable,electric copper cable |
||
Cat 5e UTP RJ45-RJ45 Network Jumper
Products Application:
1. Mainly Used in the Building Correspondence Synthesis Wiring System the Work Area.Correspondence Leading-out Terminal and between the Connection Distribution Frame Wiring.
2. As Well As the Housing Synthesis Wiring System’s User Correspondence Leading-out.Terminal Arrives at Place of Exile between Coils’ wiring.
Specification:
| Asignment: | Straight Ethernet Cable, Crossover Ethernet Cable. EIA/TIA 568A 568B |
| Catagory: | Cat3, Cat5, Cat5e, Cat6, Cat6a, Cat7 |
| Shield: | UTP, STP, SSTP |
| Conductor: | Tcu, Cu, CCA, CCS, ALMG. 30AWG, 28AWG, 26AWG, 24AWG, 22AWG |
| Length: | 0.25m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 10m, 15m, 20m, 30m, 50m, 80m,100m,etc. |
| Color: | Black, White, Grey, Blue, Green, Red, Orange, Yellow, Purple, Pink, Transparant, etc. |
Features:
Cat5e lan cable/Cat6 lan cable,network cable,ethenet cable
1)Tranmission frequency:100-350MHZ
2)Transmission speed:100-1000mbps
3)Transmission range:100-250m
4)Compliance:ETL verified ANSI TIA/EIA568-2,UL Subject 444.(UL) c(UL) type CMR/CMG.Type CM/CMH.Type CM/CMH,NEC Srticle 800 Type CMP or CM.ISO/IEC 11801.ROHS Compliant.
5)Application: 100 Base-TX, 100VG-AnyLAN, 1000Base-T, ATM, Noisy Environment
6)Electrical characteristics:
*Impedance: 100 ± 15Ω
*Static electric capacity: 17.1nf/kF (maximum)
*Resistance: 28.6/kF (maximum)
*Unbalance resistance: 5% (maximum)
*Unbalance capacity: 330pF/100m (maximum)
*Communicate rate: 65%
| UTP FTP SFTP Cat5e Lan Cable,Network Cable | |
| Conductor material | CCA25%, Copper100%,CCAG40% |
| Conductor diameter | Solid one: 0.4mm, 0.45mm, 0.5mm |
| Stranded one: 24 AWG, 26 AWG, 28 AWG | |
| Num of Conductor | 2P, 4P, 5P,10P,20P,50P |
| Insulation material | HDPE |
| Insulation diameter | 0.9±0.02mm |
| Jacket material | PVC, ROHS PVC, LSZH |
| Print words on Cable | CAT5E 4PR/24AWG VERIFIED TO EIA/TIA 568B.2 ISO/IEC 11801 EN501 |
| UTP FTP SFTP Cat6 Lan Cable,Network Cable | |
| Conductor material | CCA25%, Copper100%,CCAG40% |
| Conductor diameter | Solid one: 0.5mm, 0.56mm, 0.57mm |
| Stranded one: 23AWG, 24 AWG,28AWG | |
| Num of Conductor | 2P,4P,5P,10P,20P,50P |
| Insulation material | PE , HDPE |
| Insulation diameter | 0.9±0.02mm |
| Jacket material | PVC, ROHS PVC, LSZH |
| Print words on Cable | CAT6 4PR/24AWG VERIFIED TO EIA/TIA 568B.2 ISO/IEC 11801 EN501 |
